opgw optic cable for 220kv line 48 Core Opgw Cable
The central stainless steel tube is surrounded by single or double
layers of aluminum clad steel wires(ACS) or mix ACS wires and
aluminum alloy wires. are the most widely used cables ,their design
is fully adapted to the most common electric line needs.
Applications
1.Optical fiber composite ground wire [OPGW] is suitable for
installation on new power lines with double function of ground wire
and communication.
2.Especially for installation on normal voitage and extra high
voltage power lines.
3.lighting protection and conduct the short circuit current.
Technical Data
|
| Structure Details | | Named | No. | Diameter |
| Center | 20%AS wire | 1 | 2.70 | mm |
| Layer 1 | 20%AS wire | 4 | 2.70 | mm |
| SUS-Tube | 2 | 2.70 | mm |
| Layer 2 | 20%AS wire | 10 | 2.70 | mm |
| | | | | |
| According to IEEE std 1138,IEC 60794-4 standards | | | | |
| Fiber No. & Type | | | 48 | G652D |
| Standard Diameter | | | 13.50 | mm |
| Supporting Cross Section | | | 97.30 | mm2 |
| | Section of AS wire | | 97.30 | mm2 |
| Approximate mass | | | 687.0 | kg/km |
| Rated Tensile Strength | | | 117.0 | kN |
| Maximum Allowable Tension(40%RTS) | | | 46.8 | N/mm2 |
| Everyday Stress(25%RTS) | | | 29.3 | N/mm2 |
| Strain Margin Stress(70%RTS) | | | 81.9 | N/mm2 |
| Modulus of Elasticity | | | 162.0 | GPa |
| Thermal Elongation Coefficient | | | 13.0 | ×10-6/ºC |
| Calculated D.C. Resistance at 20ºC | | | 0.878 | Ω/km |
| Short-Circuit Current Capacity(40~200ºC, 0.25s) | | | 45.3 | kA2·s |
| Ratio between Pull and Weight | | | 17.40 | km |
| Temperature | Installation | | | -10ºC~+50 | ºC |
| Range: | Transportation and Operation | | | -40ºC~+80 | ºC
|
Cross Section
